2. Parts
  3. Model 10671 - Serial 290000001 - 290999999

Insight Lawn Mower

Product Information

  • Model #: 10671
  • Serial #: 290000001 - 290999999
  • Product Type: Walk Behind Mowers

  • Model #: 110-8800
    Lawn-Boy Leaf Green Paint, 4.5 oz. spray can
  • Model #: 110-8801
    Height-Of-Cut Kit, Insight Lawn Mowers
  • Model #: 112-8770
    KIT-LOOSE PARTS (CANADA)
  • Model #: 89815
    WPM REPLACEMENT BAG
  • Model #: 89913
    LB 21" MODULAR WPM REAR BAG KIT
  • Model #: 89914
    LB 21" MODULAR WPM BLADE
  • Model #: 89945
    LB AIR FILTER 4 CYCLE 6.5 TECUMSEH HO
  • Model #: 89946
    LB SPARK PLUG 4-CYCLE 6.5 TECUMSEH HO
  • Model #: 89951
    Cup Holder, Walk-Behind Lawn Mowers

  • Model #
    10671
  • Serial #
    290000001 - 290999999
  • Product Name
    Insight Lawn Mower
  • Product Brand
    Lawnboy
  • Product Type
    Walk Behind Mowers
  • Product Series
    21" Steel Deck
  • Chassis Type
    Steel Deck WPM
  • Swath
    21 inch
  • Discharge
    Mulcher
  • Engine/Motor Manufacturer
    Tecumseh
  • Engine/Motor Size
    195cc
  • Engine/Motor Type
    4 Cycle EPA2
  • Engine Starter
    Recoil
  • Transmission Type
    Hand Push
  • Traction Type
    NA

  • Engine: Engine Speed
    3000±150 RPM
  • Engine: Ignition Coil Air Gap
    .012" / .3mm
  • Engine: Spark Plug
    Champion RJ19LM
  • Engine: Spark Plug Gap
    .030"/ .76mm
  • Engine: Engine Oil Type
    20 oz. (.6l) 30w / API SH or higher
  • Chassis: Height of Cut Range
    1" - 4" (2.5-10 cm)
